384 Diagnostics and maintenance
ACH550-02 User's Manual
2008 PANEL LOSS Panel communication is lost and either:
• the drive is in local control mode (the control
panel displays HAND), or
• the drive is in remote control mode (AUTO) and
parameterized to accept start/stop, direction or
reference from the control panel.
To correct check:
• communication lines and connections
• parameter 3002
PANEL COMM ERR
• parameters in Group 10: START/STOP/DIR and
Group 11: REFERENCE SELECT (if drive
operation is AUTO).
2009
DEVICE
OVERTEMP
Drive heatsink is hot. This alarm warns that a DEV
OVERTEMP fault may be near.
Check for and correct:
• fan failure
• obstructions in the air flow
• dirt or dust coating on the heat sink
• excessive ambient temperature
• excessive motor load.
2010
MOTOR TEMP Motor is hot, based on either the drive’s estimate or
on temperature feedback. This alarm warns that a
MOT OVERTEMP fault trip may be near.
• Check for overloaded motor.
• Adjust the parameters used for the estimate
(3005…3009).
• Check the temperature sensors and Group 35:
MOTOR TEMP MEAS parameters.
2011
RESERVED Not used.
2012
MOTOR STALL Motor is operating in the stall region. This alarm
warns that a
MOTOR STALL fault trip may be near.
2013
See
Note 1
AUTORESET This alarm warns that the drive is about to perform
an automatic fault reset, which may start the motor.
• To control automatic reset, use Group 31:
AUTOMATIC RESET.
Alarm
code
Display Description
