130 Real-time clock and timed functions
ACH550-02 User's Manual
Using the timer
You can use the Timed Functions Assistant for easy configuring.
For more information on the assistants, see page 80. The timer
is configured in four stages. They are:
1. Enabling the timer. Configure how the timer is activated.
See page 132.
2. Setting the time period. Define the time and day when the
timer operates. See page 133.
3. Creating the timer. Assign the selected time period to
certain timer(s). See page 134.
4. Connecting the parameters. Connect selected parameters
to the timer. See page 135.
TIME PERIOD 1
3602 START TIME 1
3603 STOP TIME 1
3604 START DAY 1
3605 STOP DAY 1
TIME PERIOD 4
3614 START TIME 4
3615 STOP TIME 4
3616 START DAY 4
3617 STOP DAY 4
TIME PERIOD 3
3610 START TIME 3
3611 STOP TIME 3
3612 START DAY 3
3613 STOP DAY 3
TIME PERIOD 2
3606 START TIME 2
3607 STOP TIME 2
3608 START DAY 2
3609 STOP DAY 2
BOOSTER
3622 BOOST SEL
3623 BOOST TIME
2
TIMER 1
3626 TIMER 1 SRC
TIMER 2
3627 TIMER 2 SRC
TIMER 3
3628 TIMER 3 SRC
TIMER 4
3629 TIMER 4 SRC
3
DI1…DI6
DI1(INV)…DI6(INV)
Start/Stop, opens dampers
according to period 1
Activates PID during
set periods 2 and 3
Changes PID setpoint according
to period 4 and boost
Activates boost
