ABB ACH550-02-645A-4 [174/454] Group 99 start up data

170 Parameter listing and descriptions

ACH550-02 User's Manual

Group 99: START-UP DATA

This group defines special start-up data required to:

• set up the drive

• enter motor information.

Code Description Range

9901 LANGUAGE 0…16

Selects the display language.

9902 APPLIC MACRO 1…14, 0…-4

Selects an application macro, or loads or saves a parameter set.

Application macros automatically edit parameters to configure the

ACH550 for a particular application.

HVAC DEFAULT 2=SUPPLY FAN 3=RETURN FAN 4=COOLING TOWER

FAN 5=CONDENSER 6=BOOSTER PUMP 7=PUMP ALTERNATION

8=INTERNAL TIMER 9=INTERNAL TIMER WITH CONSTANT SPEEDS

10 =

FLOATING POINT 11 = DUAL SETPOINT PID 12 = DUAL SETPOINT PID

WITH CONSTANT SPEEDS 13 = E-BYPASS 14 = HAND CONTROL 0=USER S1

LOAD -1 = USER S1 SAVE -2 = USER S2 LOAD -3 = USER S2 SAVE -4 = OR

SET LOAD

1…14 – Selects an application macro.

-1 =

USER S1 SAVE, -3 = USER S2 SAVE – Saves a user parameter set into

the drive permanent memory for later use.

• Each set contains parameter settings, including Group 99: START-

UP DATA, and the results of the motor identification run.

USER S1 LOAD, -2 = USER S2 LOAD – Takes a user parameter set

back in use.

-4 =

OR SET LOAD – Loads the override parameter set manually.

• The automatic saving and loading of the override parameter set is

defined by Group 17: OVERRIDE.

0 = ENGLISH 1 = ENGLISH (AM)2 = DEUTSCH 3 = ITALIANO

4 = ESPAÑOL 5 = PORTUGUES 6 = NEDERLANDS 7 = FRANCAIS

8 = DANSK 9 = SUOMI 10 = SVENSKA 11 = RUSSKI

12 = POLSKI 13 = TÜRKÇE 14 = CZECH 15 = MAGYAR

16 = ELLINIKA 17 = CHINESE
