Technical data 413
ACH550-02 User’s Manual
Ambient conditions
The table below lists the ACH550 environmental requirements.
Ambient environment requirements
Installation site Storage and transportation in the
protective package
Altitude • 0…1000 m (0…3,300 ft)
• 1000…2000 m
(3,300…6,600 ft) if P
N
and
I
2N
derated 1% every
100 m above 1000 m
(300 ft above 3,300 ft)
• 2000…4000 m
(6,600…13,200 ft): Contact
your local ABB
representative.
Ambient temperature • -15…40 °C (5…104 °F), no
frost allowed
• Max. 50 °C (122 °F) if P
N
and I
2N
derated to 90%
-40…70 °C (-40…158 °F)
Relative humidity 5…95% , no condensation
allowed
Contamination levels
(IEC 721-3-3)
• No conductive dust allowed
• The ACH550 should be
installed in clean air
according to enclosure
classification.
• Cooling air must be clean,
free from corrosive
materials and free from
electrically conductive dust.
• Chemical gases: Class 3C2
• Solid particles: Class 3S2
Storage
• No conductive dust allowed
• Chemical gases: Class 1C2
• Solid particles: Class 1S2
Transportation
• No conductive dust allowed
• Chemical gases: 2C2
• Solid particles: Class 2S2
Sinusoidal vibration
(IEC 60068-2-6)
• Mechanical conditions:
Class 3M4 (IEC60721-3-3)
• 2…9 Hz 3.0 mm (0.12 in)
• 9…200 Hz 10 m/s
2
(33 ft/s
2
)
Storage
• Max. 1 mm (0.04 in)
(5 to 13.2 Hz),
max. 7 m/s
2
(23 ft/s
2
)
(13.2 to 100 Hz) sinusoidal
Transportation
• Max. 3.5 mm (0.14 in)
(2 to 9 Hz),
max. 15 m/s
2
(49 ft/s
2
)
(9 to 200 Hz) sinusoidal
Shock (IEC 68-2-29) Not allowed Max.100 m/s
2
(330 ft/s
2
), 11 ms
Free fall Not allowed • 100 mm (4 in)
