188 Parameter listing and descriptions
ACH550-02 User's Manual
1002 EXT2 COMMANDS 0…14
Defines external control location 2 (
EXT2) – the configuration of start,
stop and direction commands.
• See parameter 1001
EXT1 COMMANDS above.
1003 DIRECTION 1…3
Defines the control of motor rotation direction.
1 =
FORWARD – Rotation is fixed in the forward direction.
2 =
REVERSE – Rotation is fixed in the reverse direction.
3 =
REQUEST – Rotation direction can be changed on command.
