Preparing for installation 25
ACH550-02 User’s Manual
Requirements table
The table below shows how to select the motor insulation
system and when external du/dt limitation and insulated N-end
(non-drive end) motor bearings are required. The motor
manufacturer should be consulted regarding the construction of
the motor insulation and additional requirements for explosion-
safe (Ex) motors. Failure of the motor to fulfil the following
requirements or improper installation may shorten motor life or
damage the motor bearings. ACH550-02 devices have common
mode filters (CMF) as standard accessories.
All ABB motors are equipped with insulated motor non-drive end
bearings.
Random wound motors and generators of series M2_ and M3_
Motor type Voltage Standard
motor
Standard motor
+ insulated N-bearing
Standard motor
+ insulated N-bearing
+ common mode filter
Random
wound
standard
motors (non-
Ex) and
generators
U
N
< 500 V P
N
< 100 kW 100 kW < P
N
< 350 kW
or
IEC 315 <
frame size
<
IEC 355
P
N
> 350 kW
or
IEC 400 <
frame size
<
IEC 450
Random
wound high-
output motors
and other non-
harmonised
designs
U
N
< 500 V P
N
<55kW P
N
> 55 kW P
N
> 200 kW
Random
wound motors
for hazardous
environments
(Ex-motors)
U
N
< 500 V < IEC 250 > IEC 280 > IEC 355
Random wound motors and generators of series HX_ and AM_
Winding type Protective measures
0<U
N
< 500 V Enamelled wire with fibre glass taping + insulated N-bearing
Form wound low voltage motors of series AM_ and HX_
Protective measures
• insulated bearing construction
• common mode filter (CMF)
Non-ABB motors, random wound and form wound windings
Insulation level Protective measures
P
N
< 100 kW 100 kW < P
N
<350kW P
N
> 350 kW
Standard Û
LL
=
1300 V
0V<U
N
<
420 V
- + insulated N-bearing + insulated N-bearing
