Serial communications 165
ACH550-02 User's Manual
EFB CON FILE 29 6306h
FORCE TRIP 30 FF90h
EFB 1 31 FF92h
EFB 2 32 FF93h
EFB 3 33 FF94h
MOTOR PHASE 34 FF56h
OUTP WIRING 35 FF95h
INCOMPATIBLE SW 36 630Fh
CB OVERTEMP 37 4110h
USER LOAD CURVE 38 FF6Bh
SERF CORRUPT 101 FF55h
SERF MACRO 103 FF55h
DSP T1 OVERLOAD 201 6100h
DSP T2 OVERLOAD 202 6100h
DSP T3 OVERLOAD 203 6100h
DSP STACK ERROR 204 6100h
CB ID ERROR 206 5000h
EFB LOAD ERROR 207 6100h
PAR HZRPM 1000 6320h
PAR PFA REF NEG 1001 6320h
PAR AI SCALE 1003 6320h
PAR AO SCALE 1004 6320h
PAR PCU 2 1005 6320h
PAR EXT RO 1006 6320h
PAR FIELDBUS MISSING 1007 6320h
PAR PFA MODE 1008 6320h
PAR PCU 1 1009 6320h
PAR PFA & OVERRIDE 1010 6320h
PAR OVERRIDE 1011 6320h
PAR PFA IO 1 1012 6320h
PAR PFA IO 2 1013 6320h
PAR PFA IO 3 1014 6320h
Not used 1015 6320h
PAR USER LOAD C 1016 6320h
