Contents of this manual 13
ACH550-02 User’s Manual
The figure below warns about wheeling the drive.
WARNING! Do not wheel the drive except for installation (the
front wheels are preferable because the front wheels are
steadier). The drive frame may be deformed if wheeled when the
pedestal is removed. If the drive is moved over long distances,
place it on its back on a pallet and move it by forklift.
Do not wheel for long distances.
Back Front
