Biostar T-Series TForce4/ TForce4 U
User’s Manual
25
CPU Overclock Setting:
CPU Voltage:
This function will increase CPU stability when overclocking.
However, the CPU temperature will increase when CPU
voltage is increased.
Choices: The range is from 1.2V to 1.725V, with an interval of
0.0.25V.
CPU Frequency:
CPU Frequency is directly in proportion to system performance.
To maintain the system stability, CPU voltage needs to be
increased also when raising CPU frequency.
Choices: This range is from 200 to 450, with an interval of
1MHz.
Hammer CPU Multiplier:
The MOS allows users to downgrade the CPU ratio when
overclocking.
Choices: The lower limit is x4 (800MHz). The upper limit is
decided by different CPU type. With an x1 (200MHz) interval.
Memory Overclock Setting:
Memory Voltage :
This function will increase memory stability when overclocking.
Choices: The range is from 2.6V to 2.9V, with an interval of
0.1V.
Me mclock Fre que ncy:
To get better system performance, sometimes downgrading the
memory frequency is necessary when CPU frequency is
adjusted over the upper limit.
Choices: 100, 133, 166, 200, 216, 233, 250 (MHz).
PCI-Express Overclock Setting:
PCIE Clock:
It helps to increase VGA card performance.
Choices: The range is from 100 to 145, with an interval of
1MHz.
Chipset Overclock Setting:
NB/SB Voltage Regulator:
This function will increase chipset stability when overclocking.
Choices: 1.52V, 1.60V, 1.68V, 1.76V.
HT Fre que ncy:
We recommend users to set this item at “x4” when
overclocking.
Choices: x1, x2, x3, x4, x5, Auto.
