![Biostar TForce4 U [52/100] Italian](/views2/1711956/page52/bg34.png)
Biostar T-Series TForce4/ TForce4 U
User’s Manual
50
ITALIAN
CPU
Supporto di Socket 939.
Supporto di processori AMD Athlon 64 FX / Athlon 64 / Athlon 64
X2.
Supporto processore AMD Sempron.
L’architettura AMD 64 abilita la computazione simultanea 32 e 64
bit.
Supporto delle tecnologie HyperTransport™ e AMD
Cool’n’Quiet™.
Chipset
NVIDIA nForce4 (TForce4).
NVIDIA nForce4 Ultra (TForce4 Ultra).
Entrambi supportano:
Supporto di NVIDIA Firewall.
Supporto di Gigabit Ethernet.
Supporto di NVIDIA nTune Utility.
Supporto del processore NVIDIA Secure Networking.
ortati
Supporto di Windows 2000 e Windows XP.
Nota: Non supporta Windows 98SE e Windows ME.
Dimensioni
Fattore di forma ATX: 29.35cm (L) x 23.4 cm (P)
Memoria di sistema
Supporto di moduli DDR a doppio canale.
Supporto di DDR333 /DDR400.
Lo spazio massimo di memoria è 16GB e supporta 4 prese DIMM.
Serial AT A
nForce4 Ultra supporto specifiche Serial ATA 2.0, velocità di
trasferimento dei dati fino 3GB/s.
nForce4 supporto specifiche Serial ATA 2.0, velocità di
trasferimento dei dati fino 1.5GB/s.
Super I/O
Chip: ITE IT8712F.
Funzioni di controllo dell’ambiente:
Monitoraggio hardware
Controller velocità ventolina
Funzione "Smart Guardian" di ITE
IDE
Due connettori integrati supportano 4 dispositivi.
Modalità: PIO 0-4, bus master Block e Ultra DMA 33/66/100/133.
Audio Codec AC’97
Chip: ALC850, supporto di 8 canali.
Chip IEEE 1394A
