![Biostar TForce4 U [60/100] Russian](/views2/1711956/page60/bg3c.png)
Biostar T-Series TForce4/ TForce4 U
User’s Manual
58
RUSSIAN
Процессор
Поддерживает гнездо 939..
Поддерживает процессоры AMD Athlon 64 FX, Athlon 64, Athlon
64 X2
Поддерживает процессорыAMD Sempron.
Архитектура AMD 64 допускает одновременную работу в
32-разрядном и 64-разрядном режимах.
Поддерживает технологии HyperTransport™ и AMD
Cool’n’Quiet™
Набор микросхем
NVIDIA nForce4 (TForce4).
NVIDIA nForce4 Ultra (TForce4 Ultra).
Поддерживают оба:
Поддерживает брандмауэр NVID IA.
Поддерживает сетевой интерфейс Gigabit Ethernet.
Поддерживает программу NVIDIA nTune.
Поддерживает процессор NVIDIA Secure Networking Processor.
Поддерживаемые операционные системы
Поддерживает Windows 2000 и Windows XP.
Примечание: не поддерживает Windows 98SE и Windows ME.
Размеры
Форм-фактор ATX: 29.35cm (L) x 23.4cm (W)
Системная память
Поддержка двухканальной памяти DDR.
Поддерживает DDR333 / DDR400.
Максимальный объем памяти 16 Гб в 4 гнездах DIMM.
Serial ATA
nForce4 Ultra поддерживает спецификацию Serial ATA 2.0,
скорость передачи данных до или 3 Гб/с.
nForce4 поддерживает спецификацию Serial ATA 2.0, скорость
передачи данных до или 1.5 Гб/с.
Супер ввод-вывод
Контроллер: ITE IT8712F.
Функции управления режимом эксплуатации,
Монитор состояния оборудования
Контроллер скорости вентиляторов
Функция «Smart Guardian» компании ITE
IDE
Два встроенных разъема поддерживают подключение четырех
жестких дисков IDE.
Поддержка режимов PIO 0~4, Block Mode и Ultra DMA
33/66/100/133.
Звуковой кодек AC’97
Контроллер::ALC850, поддерживает 8-канальный звук.
Контроллер IEEE 1394A
