Biostar T-Series TForce4/ TForce4 U
User’s Manual
27
V8 Tech Engine:
This setting will raise about 15%~25% of whole system
performance.
V12 Tech Engine:
This setting will raise about 25%~30% of whole system
performance.
Notices:
1. Not all types of AMD CPU perform above overclock setting ideally; the difference
will be based on the selected CPU model.
2. From BET experiments, the Atholon64 FX CPU is not suitable for this A.O.S.
feature.
