Biostar T-Series TForce4/ TForce4 U
User’s Manual
1
CHAPTER 1: INTRODUCTION
1.1 MOTHERBOARD FEATURES
CPU
Supports Socket 939.
Supports AMD Athlon 64 FX / Athlon 64 /Athlon 64 X2 processors.
Supports AMD Sempron processor.
AMD 64 architecture enables simultaneous 32 and 64 bit
computing.
Supports HyperTransport and AMD Cool’n’Quiet Technology.
Chipset
NVIDIA nForce4 for TForce4
NVIDIA nForce4 Ultra for TForce4 Ultra.
Both support:
Supports NVIDIA Firewall.
Supports Gigabit Ethernet.
Supports NVIDIA nTune Utility.
Supports NVIDIA Secure Networking Processor.
Operating Systems
Supports Windows 2000 and Windows XP.
Note: Does not support Windows 98SE and Windows ME.
Dimensions
ATX Form Factor: 23.4cm (W) x 29.35cm (L)
Main Memory
Supports Dual Channel DDR.
Supports DDR333 and DDR400.
Maximum memory space is 4GB, supporting 4 DIMM sockets.
Serial AT A
nForce4 Ultra supports SATA 2.0 specification, with data transfer
rates up to 3Gb/s.
nForce4 supports SATA 1.0 specification, with data transfer rates
up to 1.5Gb/s.
Super I/O
Chip: ITE IT8712F.
Environment Control initiatives
H/W Monitor
Fan Speed Controller
ITE's "Smart Guardian" function
IDE
2 on-board connectors support 4 IDE disk drives.
Supports PIO mode 0-4, Block Mode and Ultra DMA
33/66/100/133 bus master mode.
