TForce4 / TForce4 Ultra
26
Start PWM Value
The Choices: 32 (default).
Slope PWM
The Choices: 1 PWM Value/ (default)℃ , 2 PWM Value/℃, 4 PWM Value/℃, 8
PWM Value/℃,16 PWM Value/℃,32 PWM Value/℃, 64PWM Value/℃.
Show H/ W Mo nitor in POST
If your computer contains a monitoring system, it will show PC health status during
POST stage. The item offers several delay time for you to choose.
The Choices: Disabled (default), Enabled.
CPU Vcore/ +1.5V+3.3V/ +5.0V/ +12.0V/ 5V<SB>/ Voltage Battery
Detect the system’s voltage status automatically.
CPU Te mperat ure
This field displays the current temperature of the CPU.
Current CPU FAN Speed
This field displays the current speed of CPU fan.
Current SYS FAN Speed
This field displays the current speed SYSTEM fan.
