Biostar T-Series TForce4/ TForce4 U
User’s Manual
55
Chip IEEE 1394A
Chip: VIA VT6307, suporta duas portas Firewire 1394A até 400
Mb/s para cada uma
LAN Ethernet Gigabit
NVIDIA Gigabit MAC + VITESSE Gigabit PHY VSC8201.
Suporta a gestão de energia ACPI.
Suporta a tecnologia NVIDIA StreamThru
Controlador isócrono combinado com a arquitectura
Hyper Transport para um desempenho mais rápido ao
nível da rede.
Segurança
Tecnologia de firewall NVIDIA
Firewall nativa, para protecção do PC contra intrusos
através da filtragem de tráfego não autorizado.
NVIDIA Active Armor (apenas para os modelos nForce4 Ultra)
Melhora a segurança da rede e proporciona aos
utilizadores um ambiente rápido e seguro.
Tecnologia NVIDIA RAID
RAID 0 função "disk striping" para um melhor desempenho por
parte do sistema e das aplicações.
RAID 1 suporta a função "disk mirroring" para tolerância de falhas,
suporta as normas SATA e ATA-133 ao nível do controlador do
disco.
Suporta as funções RAID 0+1 “disk striping” e “mirroring” para um
desempenho superior com tolerância de falhas.
Conectores e ranhuras internos na placa
1 ranhura PCI Express x16
1 ranhura Xtreme Graphics
1 conector S/PDIF-Out
1 conector CD-ROM para entrada de áudio
2 ranhuras PCI Express x1
2 conectores Ultra DMA 133/100/66/33 IDE
3 ranhuras PCI
4 portas Serial ATA
Conectores I/O do painel traseiro
1 porta impressora
1 tomada LAN RJ-45
1 porta para rato PS/2
1 porta para teclado PS/2
1 porta Firewire 1394A
1 porta série (COM2 opcional)
4 portas USB 2.0
6 portas de áudio para saída de 8 canais de áudio.
