![Biostar TForce4 U [44/100] Manual](/views2/1711956/page44/bg2c.png)
Biostar T-Series TForce4/ TForce4 U
User’s Manual
42
Manual
Aside from the paperback manual, we also provide manual in
the Driver CD. Click on the Manual icon to browse for available
manual.
Note:
You will need Acrobat Reader to open the manual file. Please download the
latest version of Acrobat Reader software from
http://www.adobe.com/products/acrobat/readstep2.html
5.2 AWARD BIOS BEEP CODE
Beep Sound Meaning
One long beep followed by two
short beeps
Video card not found or video card
memory bad
High-low siren sound
CPU overheated
System will shut down
automatically
One Short beep when system
boots-up
No error found during POST
Long beeps every other second No DRAM detected or installed
