TForce4 / TForce4 Ultra
18
Parallel Port Mode
The default value is SPP.
The Choices:
SPP(default) Usin g Paralle l port as Standard P rinter Port.
EPP Usin g Paralle l P ort as Enhanced Paralle l P ort.
ECP Using Parallel port as Extended Capabilities Port.
ECP +EPP Usin g Paralle l port as ECP & EPP mode.
ECP Mode Use DMA
Select a DMA Channel for the port.
The Choices: 3 (default), 1.
IDE HDD Block Mode
Block mode is also called block transfer, multiple commands, or multiple sector
read / write. If your IDE hard drive supports block mode (most new drives do),
select Enabled for automatic detection of the optimal number of block mode (most
new drives do), select Enabled for automatic detection of the optimal number of
block read / write per sector where the drive can support.
The Choices: Enabled (default), Disabled.
