![Biostar TForce4 U [64/100] Japanese](/views2/1711956/page64/bg40.png)
Biostar T-Series TForce4/ TForce4 U
User’s Manual
62
JAPANESE
CPU
Socket 939 をサポート。
AMD Athlon 64 FX / Athlon 64 / Athlon 64 X2 プロセッサをサポー
ト。
AMD Se mpron プロセッサをサポート。
AMD 64 アーキテクチャにより、32 ビットと 64 ビットの同時コン
ピューティングが可能。
HyperTransport および AMD Cool’n’Quiet テクノロジをサ
ポート。
チップセット
NVIDIA nForce4 (TForce4).
下記に両方とも対応:
NVIDIA ファイアウォールをサポート。
Gigabit イーサネットをサポート。
NVIDIA nTune ユーティリティをサポート。
NVIDIA セキュアネットワーキングプロセッサをサポート。
サポートするオペレーティングシステム
Windows 2000、Windows XP をサポート。
注
: Windows 98SE
と
Windows ME
では
対応
していません
。
サイズ
AT X フォームファクタ: 29.35cm (長さ) x 23.4cm (幅)
システムメモリ
デュアルチャンネル DDR をサポート。
DDR333 / DDR400 をサポート。
最大メモリ容量 16GB、4 つの DIMM ソケットをサポート。
シリアル ATA
nForce4 Ultra シリアル AT A 2.0 仕様をサポート、最大 3GB/秒の
データ転送速度。
nForce4 シリアル AT A 1 . 0 仕様をサポート、最大 1.5GB/秒のデー
タ転送速度。
スーパー I/O
チップ: ITE IT8712F。
環境コントロールイニシアチブ、
H/W モニタ
ファン速度コントローラ
ITE「スマート・ガーディアン」機能
IDE
2つのオンボードコネクタが 4 つのデバイスをサポート。
PIO モード 0-4、ブロックモード、ウルトラ DMA 33/66/100/133
