Biostar T-Series TForce4/ TForce4 U
User’s Manual
47
AC’97 Sound-Codec
Chip: ALC850, unterstützt 8 Kanäle.
IEEE 1394A Chip
Chip: VIA VT6307, unterstützt zwei 1394A Firewire-Anschlüsse
jeweils mit einer Geschwindigkeit von bis zu 400Mb/s.
Gigabit Ethernet-LAN
NVIDIA Gigabit MAC + VITESSE Gigabit PHY VSC8201.
Unterstützt die ACPI-Energieverwaltung.
Unterstützt NVIDIA StreamThru-Technologie
Isochroner Controller gekoppelt mit Hyper Transport
garantiert höchste Netzwerkleistung.
Sicherheit
NVIDIA Firewall-Technologie
Native Firewall-Lösung, schützt den PC durch Filtern
unautorisierten Datenverkehrs vor Eindringlingen.
NVIDIA Active Armor (nur für nForce4 Ultra)
Verbesserte Netzwerksicherheit bietet sowohl schnellere
als auch sicherere Umgebung.
NVIDIA RAID Technologie
RAID 0 Disk-Striping für die höchste System- und
Applikationsleistung.
RAID 1 Disk-Mirroring zur Erhöhung der Fehlertoleranz,
unterstützt die SATA und ATA-133 Disk-Controller-Standards.
RAID 0+1 Disk-Striping und -Mirroring für die höchste Leistung mit
Fehlertoleranz.
Interne integrierte Steckplätze und Anschlüsse
1 PCI-Express x16-Steckplatz
1 Xtreme Graphics Steckplatz
1 CD-ROM-Audioeingang
1 S/PDIF-Ausgangsanschluss
2 PCI-Express x1-Steckplätze
2 Ultra DMA 133/100/66/33 IDE-Anschlüsse
3 PCI-Steckplätze
4 Serial ATA-Anschlüsse
Rücktafel-E/A-Anschlüsse
1 drucker Anschluss
1 RJ-45 LAN-Anschluss
1 PS/2-Mausanschluss
1 PS/2-Tastaturanschluss
1 1394A Firewire-Anschluss
1 serieller Anschluss (COM2 optional)
4 USB 2.0-Anschlüsse
6 Audioanschlüsse für 8-Kanal-Audioausgabefunktionen.
