Biostar T-Series TForce4/ TForce4 U
User’s Manual
51
Chip: VIA VT6307, supporto di due porte Firewire 1394A con
capacità massima individuale di 400Mb/s.
Gigabit Ethernet LAN
NVIDIA Gigabit MAC + VITESSE Gigabit PHY VSC8201.
Supporto gestione energetica ACPI.
Supporto della tecnologia NVIDIA StreamThru
Il controller isocrono accoppiato con Hyper Transport
produce le più veloci prestazioni di rete.
Protezione
Tecnologia Firewall NVIDIA
Soluzione Firewall Native protegge il PC da intrusioni
filtrando il traffico non autorizzato.
NVIDIA Active Armor (solo per nForce4 Ultra)
Migliore la protezione di rete e fornisce agli utenti un
ambiente sia rapido sia protetto.
Tecnologia NVIDIA RAID
Striping del disco RAID 0 per prestazioni superiori del sistema e
delle applicazioni.
Supporto mirroring del disco RAID 1 per la tolleranza errori,
supporto di entrambi gli standard controller disco SATA e ATA-133.
Stripinig e mirroring disco RAID 0+1 per le massime prestazioni
con tolleranza agli errori.
Connettori e alloggiamenti interni integrato
1 alloggiamento PCI-Express x16
1 alloggiamento Xtreme Graphics
1 connettore S/PDIF-out
1 connettore ingresso audio CD-ROM
2 alloggiamenti PCI-Express x1
2 connettori Ultra DMA 133/100/66/33 IDE
3 alloggiamenti PCI
4 porte Serial ATA
Connettori I/O del pannello posteriore
1 porta stampatore
1 connettore LAN RJ-45
1 porta mouse PS/2
1 porta tastiera PS/2
1 porta Firewire 1394A
1 porta seriale (COM2 optional)
4 porte USB 2.0
6 porte audio supportano 8 canali di servizio rendimento audio.
