Biostar T-Series TForce4/ TForce4 U
User’s Manual
53
Procesador IEEE 1394
Procesador:VIA VT6307, admite dos puertos 1394A Firewire de
hasta 400 Mb/s individualmente.
LAN Ethernet Gigabit
NVIDIA Gigabit MAC + VITESSE Gigabit PHY VSC8201.
Admite administración de energía ACPI.
Admite la tecnología NVIDIA StreamThru
Controlador isócrono asociado con Hyper Transport
proporciona el mayor rendimiento para interconexión en
red.
Seguridad
Tecnología de Firewall NVIDIA
- Solución de firewall nativa, protege el computador personal
de intrusos al filtrar el tráfico no autorizado.
NVIDIA Active Armor (solamente para nForce4 Ultra)
Mejora la seguridad de la red y proporciona a los usuarios
un entorno rápido y seguro.
Tecnología NVIDIA RAID
Intercalación de disco RAID 0 disk para conseguir el mejor
rendimiento del sistema y de las aplicaciones.
Admite simetría de disco RAID 1 para tolerancia de errores,
compatible con las normas de controlador de discos SATA y
ATA-133.
Doble escritura y grabación en disco RAID 0+1 para obtener un
mayor rendimiento con tolerancia a fallos.
Conectores y ranuras de E/S integrados e internos
1 ranura 16X PCI-Express
1 ranura Xtreme Graphics
1 conector de salida S/PDIF
1 conector de entrada de audio en CD-ROM
2 ranuras 1X PCI-Express
2 conectores Ultra DMA 133/100/66/33 IDE
3 ranuras PCI
4 puertos Serial ATA
Back Conectores de E/S del panel posterior
1 puerto impresora
1 conector de red LAN RJ-45
1 puerto para ratón PS/2
1 puerto para teclado PS/2
1 puerto 1394A Firewire
1 puerto serie (COM2 opcional)
4 puertos USB 2.0
6 puertos de audio que admiten 8 conexiones de salida de audio
de 8 canales.
