Biostar T-Series TForce4/ TForce4 U
User’s Manual
52
SPANISH
Procesador
Soporta el Socket 939.
Supporta los procesadores AMD Athlon 64 FX / Athlon 64 /Athlon
64 X2.
Compatible con el procesador AMD Sempron.
La arquitectura AMD 64 permite computación de 32 bits y 64 bits
de manera simultánea.
Suporta las tecnologías HyperTransport™ y AMD Cool’n’Quiet™.
Conjunto de chips
NVIDIA nForce4 (TForce4).
NVIDIA nForce4 Ultra (TForce4 Ultra).
Ambos admiten:
Soporta el Firewall NVIDIA.
Soporta Gigabit Ethernet.
Suporta la Utilidad NVIDIA nTune.
Suporta el Procesador para Seguridad en Redes NVIDIA.
Sistemas operativos compatibles
Compatible con Windows 2000 y Windows XP.
Nota: no compatible con Windows 98SE ni Windows ME.
Dimensiones
Formato ATX: 29.35 cm (LA) x 23.4 cm (AN)
Memoria del sistema
Compatible con admite DDR de canal dual.
Compatible con admite DDR266/333/400.
Espacio máximo de memoria de 4 GB, que admite 4 zócalos
DIMM.
Serial AT A
nForce4 Ultra compatible con la especificación Serial ATA 2.0, tasa
de transferencia de datos de hasta 3 GB/s.
nForce4 compatible con la especificación Serial ATA 2.0, tasa de
transferencia de datos de hasta 1.5 GB/s.
Súper E/S
Procesador: ITE IT8712F.
Iniciativas de control medioambiental:
Supervisor H/W
Controlador de la velocidad del ventilador
Función "Guardián inteligente" de ITE
IDE
Dos conectores integrados que admiten 4 dispositivos.
Admite el modo PIO 0-4, el modo de bloque y el modo de bus
maestro Ultra DMA 33/66/100/133.
Códec de audio AC’97
Procesador: ALC850, admite 8 canales.
