Biostar T-Series TForce4/ TForce4 U
User’s Manual
54
PORTUGUESE
CPU
Suporta o socket 939.
Suporta processadores AMD Athlon 64 FX / Athlon 64 / Athlon 64
X2.
Suporta um processador AMD Sempron.
A arquitectura AMD 64 permite uma computação de 32 e 64 bits
em simultâneo.
Suporta a tecnologia HyperTransport™ e AMD Cool’n’Quiet™.
Chipset
NVIDIA nForce4 (TForce4).
NVIDIA nForce4 Ultra (TForce4 Ultra).
Suporte:
Suporta a firewall NVIDIA.
Suporta a Ethernet Gigabit.
Suporta o utilitário NVIDIA nTune.
Suporta o processador NVIDIA Secure Networking.
Sistemas operativos suportados:
Suporta o Windows 2000 e o Windows XP.
Nota: Não suporta o Windows 98SE e o Windows ME.
Dimensões
Factor de forma ATX: 29.35 cm (C) x 23.4 cm (L)
Memória do sistema
Suporta DDR de duplo canal.
Suporta módulos DDR333 / DDR400.
Capacidade máxima da memória: 4GB, suportando 4 sockets
DIMM.
Serial ATA
nForce4 Ultra suporta a especificação Serial ATA 2.0, velocidade
de transferência de dados até3 GB/s.
nForce4 suporta a especificação Serial ATA 2.0, velocidade de
transferência de dados até1.5 GB/s.
Especificação Super I/O
Chip: ITE IT8712F.
Iniciativas para controlo do ambiente,
Monitorização do hardware
Controlador da velocidade da ventoinha
Função "Smart Guardian" da ITE
IDE
Dois conectores na placa para 4 dispositivos.
Suporta o modo PIO 0-4, o modo Block e o modo bus master Ultra
DMA 33/66/100/133.
Codec de som AC'97
Chip: ALC850, suporta 8 canais.
