Biostar T-Series TForce4/ TForce4 U
User’s Manual
2
AC’9 7 Audio Sound Codec
Chip: ALC850, supports 8 channels audio output.
IEEE 1394A Chip
Chip: VIA VT6307, supports 2 ports with transfer up to 400Mb/s.
Gigabit Ethernet LAN
NVIDIA Gigabit MAC + VITESSE Gigabit PHY VSC8201.
Supports ACPI power management.
Supports NVIDIA StreamThru technology
Isochronous controller paired with Hyper Transport results
in fastest networking performance.
Security
NVIDIA Firewall technology
Native firewall solution protects the PC from intruders by
filtering unauthorized traffic.
NVIDIA Active Armor (Only for nForce4 Ultra)
Enhances network security, and provides users with an
environment both fast and secure.
NVIDIA RAID Technology
RAID 0 disk striping for highest system and application
performance
RAID 1 disk mirroring support for fault tolerance
Support for both SATA and ATA-133 disk controller standards
RAID 0+1 disk striping and mirroring for highest performance with
fault tolerance.
Internal On-board Slots and Connectors
One PCI-Express X16 slot.
One Xtreme Graphics slot.
One SPDIF-Out connector.
One CD-ROM audio-in connector.
Two PCI-Express X1 slots.
Two Ultra DMA 133/100/66/33 IDE connectors.
Three PCI slots.
Four SATA ports.
Back Panel I/O Connectors and Ports
1 Printer Port.
1 RJ-45 LAN jack.
1 PS/2 Mouse Port.
1 PS/2 Keyboard Port.
1 1394A Firewire Port.
1 Serial Port. (COM2 is optional.)
4 USB 2.0 Ports.
6 audio ports support 8 channels audio-out facilities.
