Biostar T-Series TForce4/ TForce4 U
User’s Manual
59
Контроллер: VIA VT6307, поддерживает два порта 1394A
Firewire со скростью каждого порта до 400 Мбит/с.
Гигабитный интерфейс Ethernet
NVIDIA Gigabit MAC + VITESSE Gigabit PHY VSC8201.
Поддерживает управление питанием ACPI.
Поддержка технологии NVIDIA StreamThru
Изохронный контроллер, объединенный с шиной HyperTransport для
обеспечения повышенной производительности в сети.
Безопасность
Технология брандмауэра NVIDIA
Встроены брандмауэр защищает ПК от взломщиков, отфильтровывая
неразрешенный трафик.
Межсетевой экран NVIDIA Active Armor (только для nForce4
Ultra)
Обеспечивает безопасность и скорость сетевых подключений.
Технологии NVIDIA RAID
Чередование дисков RAID 0 обеспечивает самую высокую
производительность системы и приложений.
Зеркалирование дисков RAID 1 обеспечивает
отказоустойчивость для дисков с интерфейсом SATA и
ATA-133.
Чередующиеся и зеркальные дисковые массивы RAID 0+1
обеспечивают максимальную производительность и
отказоустойчивать.
Встроенные разъемы ввода-вывода
1 слот PCI Express x16
1 слот Xtreme Graphics
1 разъем S/PDIF-выхода
1 Один входной разъем звукового сигнала с привода для
компакт-дисков
2 слота PCI Express x1
2 разъем Ultra DMA 133/100/66/33 IDE
3 слота PCI
4 порта Serial ATA
Разъемы ввода-вывода на задней панели
1 порт принтер
1 гнездо RJ-45 ЛВС
1 порт мыши PS/2
1 порт клавиатуры PS/2
1 порт 1394A Firewire
1 последовательный порт
4 порта USB 2.0
6 звуковых портов поддерживают подключение 8 каналов
аудиовыхода.
