Biostar T-Series TForce4/ TForce4 U
User’s Manual
39
v. Auto:
If the green indicator is lit up, the Smart Fan Function
is “On” (Default Setting).
Click on this button again to close Smart Fan Function,
and a screen as below would pop-up.
There will be pulling-meter besides the CPU Fan and
System Fan, the CPU Fan and the System Fan speed
can be adjusted by adjusting the Cursor Up or Down.
vi. Program Tool Bar:
z About:
Click on this button to get program-related
information.
z Minimize:
Click on this button to minimize the program to
system tray
z Exit:
Click on this button to exit this program.
