Using scan to e-mail operations
4-18 SU-502
4.4 Specifying the destination using group dial keys
2
Note
The group dial setting must have already been specified.
For information on setting up group dial keys, refer to “Adding destina-
tions” on page 3-37.
If at least one fax number is registered as a recipient with a group dial key,
that group dial key cannot be used with the Scan to E-mail transmission.
In this case, the message
NOT E-MAIL ADDRESS
appears in the dis-
play.
How to use group dial keys
1 Press the [Scan] key.
The machine enters Scan mode, and the scan screen appears.
2 Press the one-touch dial key ([01] to
[15]) programmed with the group
where you want to send the scan da-
ta.
