Getting ready
3
SU-502 3-55
File destination
E-mail notification
Account information
Function Description
Destination name This function is used to specify the name for the file destination.
(Up to 20 characters)
FTP server address This function is used to specify the host name or IP address of the
FTP site where the scan data will be sent. (Up to 64 characters)
Directory This function is used to specify the file path of the directory on the
FTP site where the scan data will be stored. (Up to 128 charac-
ters)
Use proxy This function is used to specify whether or not to access the FTP
site via a proxy server. (For information on proxy server settings,
refer to “FTP & DNS configuration” on page 3-32.)
Remote port number This function is used to specify the remote port number (1 to
65535) if a proxy server is not being used. Normally, port number
21 is used.
Function Description
Enable notification This function is used to specify whether or not to send an e-mail
notification when scan data is uploaded to an FTP server.
Notification address This function is used to specify the e-mail addresses (up to 10)
where e-mail notifications should be sent. (Up to 64 characters)
Function Description
Anonymous This function should be selected if the FTP site is an anonymous
FTP server.
Private site If the FTP site requires user authentication, specify settings for
the following.
User name: The user name (up to 20 characters) used to log in to
the FTP site
Password: The password (up to 20 characters) associated with
the user name used to log in to the FTP site
Confirm: Used to specify the password for confirmation
bizhub160_su502.book Page 55 Tuesday, May 17, 2005 8:19 AM
