Getting ready
3
SU-502 3-31
POP3 configuration
Function Description
POP3 server address This function is used to specify the IP address or host name of the
POP3 server. (Up to 64 characters)
Account name This function is used to specify the account name used to log in
to the POP3 server. (Up to 64 characters)
Password This function is used to specify the password associated with the
account name used to log in to the POP3 server. (Up to 32 char-
acters)
Auto reception Select whether or not the Auto Reception function is used.
Interval This function is used to specify the time interval (between 1 and
60 minutes) for checking e-mail when the auto reception function
is enabled.
Reply address This function is used to specify the return e-mail address for error
messages. If an error occurs, an error message will be sent to the
e-mail address specified here. Normally, the reply address is set
to the e-mail address of the administrator. (Up to 64 characters)
Port number This function is used to specify the port number for the POP3
server. Normally, port number 110 is used. (1 to 65535)
POP3 server timeout This function is used to specify the length of time (30 to 300 sec-
onds) until the connection to the POP3 server times out.
