Konica Minolta bizhub 162fR [28/172] Symbol list

Overview

2-14 SU-502

2.6.3 About the display

Symbol list

No. Display indication Description

1 Mode or function

name

• Displays the currently selected mode or function setting.

• Displays the current settings menu or option.

• If an error occurs, displays the error message.

• During standby, displays the date and the amount of memory

available.

2 Message area Displays messages such as operating instructions.

Symbol Description

Sending/receiving e-

mail messages

An e-mail message is being sent or received.

In standby for timer

transmission

An e-mail message is queued for timer transmission.

bizhub160_su502.book Page 14 Tuesday, May 17, 2005 8:19 AM
