Overview
2-16 SU-502
For recipient names (Metric models):
For recipient names (Inch models):
* Repeatedly press the 10-key pad key to scroll through the available characters and symbols un-
til the desired character appears in the display.
10-key pad key Available characters*
1 @ . (period) @_ (underscore) - (hyphen) 1
2 ABC ABC2abcÄäÅåÆæàÇç
3DEF DEF3defÉéè
4 GHI GHI4ghiìíî
5JKL JKL5jkl
6 MNO MNO6mnoÑñÖöØøò
7 PQRS PQRS7pqrsß
8 TUV TUV8tuvÜüùú
9 WXYZ WXYZ9wxyz
0 Space (space) 0
+&/1=!?( )%[ ]^‘’{ }|˜$,:;<>"¿£
##
10-key pad Available characters*
1 @ . (period) @_ (underscore) - (hyphen) 1
2ABC ABC2abc
3DEF DEF3def
4 GHI GHI4ghi
5JKL JKL5jkl
6MNO MNO6mno
7 PQRS PQRS7pqrs
8TUV TUV8tuv
9 WXYZ WXYZ9wxyz
0 Space (space) 0
+&/1=!?( )%[ ]^‘’{ }|˜$,:;<>"¿£
##
