3
Getting ready
3-6 SU-502
DNS
CONFIG.
This function is
used to enable or
disable the DNS
(Domain Name
System) setting. If
there is a DNS
server on your net-
work, enter the IP
address of the
DNS server.
*If the DNS server
is located within
your local network,
select “ENABLE”.
If you are using the
DNS server of an
Internet service
provider (ISP) or
some other DNS
server located out-
side your local net-
work, select
“DISABLE”. Con-
sult your network
administrator for
details.
---- oo
GATEWAY
TX
This function is
used to enable the
Direct Fax func-
tion.
---oo-
E-MAIL SETTING 1
SENDER
NAME
This function is
used to specify the
sender’s name.
oo-*1 - oo
E-MAIL
ADDRESS
This function is
used to specify the
e-mail address of
the sender.
Consult your net-
work administrator
for details.
oo-*1 - oo
SMTP
SERVER
This function is
used to specify the
IP address or host
name of an SMTP
server.
Consult your net-
work administrator
for details.
ooo*3 - oo
Function Description Inter-
net
faxing
Scan
to
e-mail
Scan
to
server
Direct
fax
Setting
Con-
trol
panel
Page-
Scope
Web
Con-
nec-
tion
bizhub160_su502.book Page 6 Tuesday, May 17, 2005 8:19 AM
