Overview
2-12 SU-502
14 [Finishing] key Used to select a copy finishing function.
15 [X/Y zoom] key Used to specify different scaling proportions for the vertical and
horizontal directions.
16 [Neg. Pos.] key Press to make copies with the dark- and light-colored areas of the
document inverted.
17 Copy key Used to select between the 2in1 and the 4in1 copy functions.
18 [Copy program] key • Copy programs can be stored.
• Stored copy programs can be selected and recalled.
19 [Book separation]
key
Used to select the book separation function.
20 [Original] key Used to select between the duplex orig. function and the mixed
orig. function.
No. Part name Function
bizhub160_su502.book Page 12 Tuesday, May 17, 2005 8:19 AM
