Getting ready
3
SU-502 3-5
3.2 Network settings
Depending on the network environment in which the machine is located,
there may be some restrictions on the network functions that the machine
can use. Specify the network settings to suit the functions and environment
required for your configuration.
The network settings can be specified from the control panel of the machine
or using the administrator mode of PageScope Web Connection.
Quick overview of the network settings
Function Description Inter-
net
faxing
Scan
to
e-mail
Scan
to
server
Direct
fax
Setting
Con-
trol
panel
Page-
Scope
Web
Con-
nec-
tion
o: Required; -: Unnecessary; - : As necessary o : Possible
- : Not possible
NETWORK SETTING
IP
ADDRESS
This function is
used to specify the
IP address for the
machine.
Consult your net-
work administrator
for information
about the IP ad-
dress to use.
o*2 o*2 o*2 o*2 oo
SUBNET
MASK
This function is
used to specify the
subnet mask value
for the network.
Consult your net-
work administrator
for details.
o*2 o*2 o*2 o*2 oo
GATEWAY This function is
used to specify the
default gateway
(IP address) of a
router on the net-
work.
Consult your net-
work administrator
for details.
o*2 o*2 o*2 o*2 oo
