Getting ready

3-22 SU-502

3.3.3 Specifying other e-mail settings (“E-MAIL SETTING 2”

menu)

The settings for the e-mail setting 2 functions are specified from the “E-MAIL

SETTING 2” menu in utility mode.

This section describes how to specify setting for the following functions.

- POP3 SERVER

- POP3 PORT NO.

- POP3 TIMEOUT

- POP3 ACCOUNT

- POP3 PASSWORD

- AUTO RECEPTION

- REPLY ADDRESS

- HEADER PRINT

Note

If you wish to cancel a change to a setting before applying it, press the

[No/C] key. Press the [Yes] key after the message “STOP SETTING?” ap-

pears.
