Overview
2
SU-502 2-15
2.6.4 Entering text characters
This section describes how to enter text characters when registering a des-
tination or when entering names, for example, for one-touch dial keys.
Key operation
The 10-key pad can be used to enter numbers, text, and symbols.
Press the [123/ABC] key to switch the input mode of the 10-key pad between
numbers and letters/symbols.
When entering numbers, “[1]” appears in the display.
When entering letters or symbols, “[A]” appears in the display.
The following lists show the characters available with each key of the 10-key
pad.
For fax number and e-mail address input:
* Repeatedly press the 10-key pad key to scroll through the available characters and symbols un-
til the desired character appears in the display.
10-key pad key Available characters*
1 @ . (period) @_ (underscore) - (hyphen) 1
2ABC ABC2abc
3DEF DEF3def
4 GHI GHI4ghi
5 JKL JKL5jkl
6MNO MNO6mno
7 PQRS PQRS7pqrs
8TUV TUV8tuv
9 WXYZ WXYZ9wxyz
0 Space (space) 0
+&/1=!?( )%[ ]^‘’{ }|˜$
##
bizhub160_su502.book Page 15 Tuesday, May 17, 2005 8:19 AM
