Getting ready

3-48 SU-502

6 Enter the destination name and e-mail address below E-mail Destina-

tion, and then click the [Apply] button.

E-mail destination

Function Description

Destination name This function is used to specify the name for the speed dial entry.

(Up to 20 characters)

Destination address This function is used to specify the e-mail address. (Up to 64

characters)

bizhub160_su502.book Page 48 Tuesday, May 17, 2005 8:19 AM
