Overview

SU-502 2-19

2.7 Using PageScope Web Connection

2.7.1 When using PageScope Web Connection

In order to use PageScope Web Connection, the optional Network Interface

Card (NC-501) must be installed.

2.7.2 What is PageScope Web Connection?

PageScope Web Connection is a device control utility program provided by

the HTTP server built into the network interface card. This utility can be used

with a Web browser as an interface for remotely controlling the machine and

network interface card.

HTTP server

Access
