Getting ready
3
SU-502 3-9
HEADER
PRINT
This function is
used to specify
whether or not to
print header infor-
mation when print-
ing e-mail
messages that
have been re-
ceived.
o ---oo
PageScope Web Connection administrator mode: “Scan” tab
File
Destination
This function is
used to specify the
FTP destination
used for Scan to
Server (FTP) oper-
ations. It is used to
specify the IP ad-
dress of the FTP
server, the directo-
ry and other set-
tings.
--o --o
PageScope Web Connection administrator mode: “Network” tab
FTP
Configura-
tion
This function is
used to specify the
IP address for the
proxy server of an
FTP server.
--- --o
Function Description Inter-
net
faxing
Scan
to
e-mail
Scan
to
server
Direct
fax
Setting
Con-
trol
panel
Page-
Scope
Web
Con-
nec-
tion
*1: Required if notification of the URL is sent by e-mail.
*2: Can also be assigned automatically by the DHCP server.
*3: If there is no SMTP server available over the network, enter “0.0.0.0” as the IP address.
