Appendix
10
SU-502 10-3
10 Appendix
10.1 Specifications
Scan to e-mail / Scan to server
Internet fax
Specifications
Communications protocols E-mail transmission: SMTP, TCP/IP
FTP transmission: FTP, TCP/IP
Resolution 150 × 150 dpi, 300 × 300 dpi, 600 × 600 dpi
Data formats E-mail format: MIME
Attached file format: TIFF, PDF
Cording method MH, MR, MMR, JPEG (For color and gray mode, fixed at JPEG)
Network Ethernet LAN (10BASE-T or 100BASE-TX connection)
Specifications
Communications protocols E-mail transmission: SMTP, TCP/IP
E-mail reception: POP3, TCP/IP
Resolution Transmission: 204 × 98 dpi, 204 × 196 dpi
Reception: 204 × 98 dpi, 204 × 196 dpi, 204 × 391 dpi, 200 × 100
dpi, 200 × 200 dpi
Data formats E-mail format: MIME
Attached file format: TIFF-F
Coding method Transmission: MH
Reception: MH, MR, MMR, JBIG
Network Ethernet LAN (10BASE-T or 100BASE-TX connection)
