3
Getting ready
3-10 SU-502
3.3 Specifying network settings using the control panel
3.3.1 Specifying network settings (“NETWORK SETTING” menu)
These settings can be specified from the network settings menu in utility
mode.
This section describes how to specify settings for the following functions.
- IP ADDRESS
- SUBNET MASK
- GATEWAY
- DNS CONFIG.
- GATEWAY TX
2
Note
Be sure to consult your network administrator before specifying any of
the network settings.
If you wish to cancel a change to a network setting before applying it,
press the [No/C] key. Press the [Yes] key after the message
STOP SET-
TING?
appears.
bizhub160_su502.book Page 10 Tuesday, May 17, 2005 8:19 AM
