Operation error messages
9
SU-502 9-5
9.2 Troubleshooting
Remedies for several possible problems are described below.
Scan to e-mail transmission
Internet fax transmission
Problem Cause Remedy Page
Transmission is not pos-
sible.
The connections are in-
correct.
Check the LED indicator
on the hub and check the
connections.
-
The settings necessary
for the device are not reg-
istered.
Specify the necessary
network settings.
p. 3-5
The LAN cable is dam-
aged.
Replace the LAN cable. -
Transmission is possible,
but the image cannot be
outputted at the recipi-
ent’s terminal or compu-
ter.
The recipient’s terminal is
not able to handle the
sent image.
Change the size, resolu-
tion and coding method
so that they are support-
ed by the recipient’s ter-
minal, and then try
sending the data again.
p. 4-10
p. 4-12
The document text was
not inserted when the
data was sent.
With some e-mail appli-
cations, if an e-mail mes-
sage is received
containing no text and
only an attached file, it
may not be possible to
open the attached file.
Therefore, text should be
inserted into the docu-
ment that is sent.
p. 3-21
Problem Cause Remedy Page
Transmission is not pos-
sible.
The connections are in-
correct.
Check the LED indicator
on the hub and check the
connections.
-
The settings necessary
for the device are not reg-
istered.
Specify the necessary
network settings.
p. 3-5
The LAN cable is dam-
aged.
Replace the LAN cable. -
An interruption in the
transmission was speci-
fied, but the transmission
was not interrupted.
It takes some time to in-
terrupt an Internet fax
transmission.
Wait until the transmis-
sion is interrupted.
-
bizhub160_su502.book Page 5 Tuesday, May 17, 2005 8:19 AM
