Getting ready
3
SU-502 3-7
SMTP
PORT NO.
This function is
used to specify the
port number (1 to
65535) for the
SMTP server.
Consult your net-
work administrator
for details.
oo-*1 - oo
SMTP
TIMEOUT
This function is
used to specify the
length of time (in
seconds) until the
connection to the
SMTP server times
out. (30 to 300
seconds)
oo-*1 - oo
TEXT IN-
SERT
This function is
used to specify
whether or not text
explaining that an
image has been
attached to the e-
mail message is in-
serted when scan
data is sent as an
e-mail attachment.
oo-*1 - oo
DEFAULT
SUBJECT
This function is
used to specify the
default subject line
when sending
scan data as an e-
mail attachment.
oo-*1 - oo
E-MAIL SETTING 2
POP3
SERVER
This function is
used to specify the
IP address or host
name of the POP3
server.
Consult your net-
work administrator
for details.
o ---oo
POP3 PORT
NO.
This function is
used to specify the
port number (1 to
65535) for the
POP3 server.
Consult your net-
work administrator
for details.
o ---oo
Function Description Inter-
net
faxing
Scan
to
e-mail
Scan
to
server
Direct
fax
Setting
Con-
trol
panel
Page-
Scope
Web
Con-
nec-
tion
