Using internet faxing operations

SU-502 6-15

6 Specify the destination.

– The destinations can be specified

using the one-touch dial or group

dial keys, speed dial numbers, or

the phone book. They can also be entered directly using the 10-key

pad.

7 Press the [Start] key.

The document is scanned and stored in the machine’s memory, ready

to be sent.

bizhub160_su502.book Page 15 Tuesday, May 17, 2005 8:19 AM
