Using internet faxing operations

SU-502 6-17

4 Press the [Yes] key to delete the cur-

rently displayed transmission job.

– The Function mode menu ap-

pears.

5 To delete another queued job, press the [8] key, and then repeat steps

3 and 4.

– After you have finished deleting queued jobs, press the [No/C] key

to return to the main screen.
