Kyocera FS-1000 Plus [10/163] 2 names of parts

1-6

FS-1000/1000+

1-2 Names of parts

1-2-1 Name of parts

Figure 1-2-1 Name of parts

Optional

interface

slot cover

Parallel

interface

connector

Power switch

Inlet

Face-down output tray

Face-up output tray

Side cover

(Expanding memory slot and

optional KPDL ROM socket inside)

Top cover

MP tray

Cassette

Front cover
