Kyocera FS-1000 Plus [28/163] 2 2 expanding memory

2-8

FS-1000/1000+

2-2-2 Expanding memory

The FS-1000/1000+ comes standard equipped with 4 MB of main memory. Printer memory can be

expanded to up to the maximum 132 MB (4 MB + 128 MB) by installing an optional DIMM (Dual

In-line Memory Module).

(1) Minimum memory requirements

Refer to the table below for minimum memory requirements in various environments.

Resolution

Printing environment 300 dpi 600 dpi

HP LaserJet 5P (factory setting) 2 MB 2 MB

HP LaserJet 5P with resource protection - 10 MB

(2) DIMM specifications

Memory size in MB 8, 16, 32, 64, 128

Number of pins 72

Access speed 80 ns or faster

Parity Without

Bus width 32 bits
