Kyocera FS-1000 Plus [141/163] Mp tray feeding a4 and others excluding legal size fs 1000
![Kyocera FS-1000 Plus [141/163] Mp tray feeding a4 and others excluding legal size fs 1000](/views2/1147197/page141/bg8d.png)
A-6
FS-1000/1000+
MOTORN
(Main motor)
MHVDR
(Main charger)
THVDR
(Transfer charger)
MPFSOL
(MP feed clutch)
RESDRN
(Registration clutch)
LDEN
(Laser diode)
BIAS
(Developing bias)
ERASPW
(Eraser lamp)
PLGDRN
(Polygon motor)
JAMR
(Registration sensor)
JAMO
(Exit sensor)
COUNT
(Total counter)
0 (s) 5 10 15 20
1000
2000
7900
15060
14193
12960
12010
11410
13810
19710
18310
16660
20910
8680
8293
3298
2780
3510
VSREQ(3510)
3993
7060
8060
100
3033
3510
Drum speed: 60.00 mm/s
Paper feeding speed: 60.00 mm/s
Printing speed: 10.17 ppm
9410
9410
10323
20910
20910
*: Varies depending on paper size.
: Jam detection timing
9223
*
4423
8198
9160
VSREQ (8260)
9223
8933
15123
*
9893
15123
4. MP tray feeding, A4 and others (excluding Legal size) [FS-1000]
