10. Option paper feeder feeding, Legal size [FS-1000+]
MOTORN
(Main motor)
MHVDR
(Main charger)
THVDR
(Transfer charger)
PFMDRN
(PF feed motor)
RESDRN
(Registration clutch)
LDEN
(Laser diode)
BIAS
(Developing bias)
ERASPW
(Eraser lamp)
PLGDRN
(Polygon motor)
JAMR
(Registration sensor)
JAMO
(Exit sensor)
COUNT
(Total counter)
0 (s) 5 10 15 20
1000
2842
1000 6651
8493
13194
*
13222
8104
18098
18098
12501
9947
10659
11492
10303
15954
14557
18098
7489
7725*
7123
VSREQ (7701)
13181*
6850
1838
1472
VSREQ(2050)
2453
1771
5008
5841
100
2050
2050
*: Varies depending on paper size.
: Jam detection timing
Drum speed: 72.00 mm/s
Paper feeding speed: 240.00 mm/s
Printing speed: 10.62 ppm
7701
7571
7530*
7422
7701
15598
