Kyocera FS-1000 Plus [33/163] Getting access to the kpdl rom socket

FS-1000/1000+

2-13

Getting access to the KPDL ROM socket

Remove the printer’s side cover. Refer to Installing the DIMM on page 2-10.

Locate the socket for inserting the KPDL ROM. This socket is marked as U03S.

KPDL ROM

Socket (U03S)

Figure 2-2-11 Getting access to the KPDL ROM socket
